Lubrication
GreasingBearingsand
Bushings
ServiceInterval:Every100hours(Lubricatemore
frequentlyinheavydutyapplications)
Thevehiclehasgreasettingsthatmustbelubricated
regularlywithNo.2GeneralPurposeLithiumBase
Grease.
Thegreasettinglocationsandquantitiesareasfollows:
•Balljoints(4),tierods(2)pivotmounts(2)and
steeringcylinder(2)(
Figure40)
•Springtower(2)(Figure41)
•Clutch(1),accelerator(1),brake(1)(Figure42)
•Acceleratorarm(1)(
Figure43)
•U-joint(18),and4wheeldriveshaft(3)(Figure44)
Important:Whengreasingthedriveshaftuniversal
shaftbearingcrosses,pumpgreaseuntilitcomes
outofall4cupsateachcross.
1.Wipeeachgreasettingcleansoforeignmatter
cannotbeforcedintothebearingorbushing.
2.Pumpgreaseintoeachbearingorbushing.
3.Wipeoffexcessgrease.
Figure40
Figure41
Figure42
Figure43
