RaisingtheBoxusingtheStarter
CrankthestarterwhileholdingtheliftleverintheRaise
position.Runthestarterfor15secondsthenwait60
secondsbeforeengagingthestarteragain.Iftheengine
willnotcrank,youmustremovetheloadandbox
(attachment)toservicetheengineortransaxle.
RaisingtheBoxbyJumpingthe
HydraulicSystem
CAUTION
Beforeservicingormakingadjustmentstothe
machine,stoptheengine,settheparkingbrake,and
removethekeyfromtheswitch.Anyloadmaterial
mustberemovedfromthebedorotherattachment
beforeworkingunderaraisedbed.Neverwork
underaraisedbedwithoutpositioningthesafety
supportonthefullyextendedcylinderrod.
Note:Twohydraulichoses,eachwithamaleandfemale
quickcoupler,thattthevehiclecouplersarerequired
toperformthisoperation.
1.Backanothervehicleuptotherearofthedisabled
vehicle.
Important:Thevehicleshydraulicsystemuses
DexronIIIATF .Toavoidsystemcontamination,
makesurethevehicleusedtojumpthehydraulic
systemusesanequivalentuid.
2.Onbothvehicles,disconnectthetwoquickcoupler
hosesfromthehosessecuredtothecouplerbracket
(
Figure80).
Figure80
1.QuickcouplerhoseA
2.QuickcouplerhoseB
3.Onthedisabledvehicle,connectthetwojumper
hosestothehosesthatweredisconnected
(Figure81).Captheunusedttings.
Figure81
1.Disconnectedhoses2.Jumperhoses
4.Ontheothervehicle,connectthetwohosestothe
couplerstillinthecouplerbracket(connectthetop
hosetothetopcouplerandthebottomhosetothe
bottomcoupler)(Figure82).Captheunusedttings.
Figure82
1.Jumperhoses
5.Keepallbystandersawayfromthevehicles.
6.Startthesecondvehicleandmovetheliftlevertothe
raisepositionwhichwillraisethedisabledbox.
7.Movethehydraulicliftlevertotheneutralposition
andengagetheliftleverlock.
8.Installthebedsafetysupportontotheextendedlift
cylinder.RefertoUsingtheBedSafetySupport.
