Fuel-ShutoffValve
Thefuel-shutoffvalveislocatedbehindtheengine
andunderthefueltank(Figure11).
Usethefuel-shutoffvalvetoshutoffthefuelwhen
themachinewillnotbeusedforafewdays,when
transportingthemachinetoandfromthejobsite,or
whenthemachineisparkedinsideabuilding.
•Toopenforfuel-shutoffvalve,rotatethehandle
ofthefuel-shutoffvalveuntilitisalignedwiththe
fuelline.
•Toclosethefuel-shutoffvalve,rotatethehandle
90°tothefuelline.
g025897
Figure11
1.OFFposition2.ONposition
Drive-WheelReleaseValves
WARNING
Yourhandsmaybecomeentangledinthe
rotatingdrivecomponentsbelowtheengine
deck,whichcouldresultinseriousinjuryor
death.
Shutofftheengine,removethekey,andallow
allmovingpartstostopbeforeaccessingthe
drive-wheelreleasevalves.
WARNING
Theengineandhydrauliccomponentscan
becomeveryhot.Touchingahotengine
orhydrauliccomponentscancausesevere
burns.
Allowtheengineandhydrauliccomponents
tocoolcompletelybeforeaccessingthe
drive-wheelreleasevalves.
Locatedontheleftandrightsidesunderneaththe
frontofthemachine.
Duringnormaloperatingconditions,thewasheron
theleverispositionedoutsidetheslots.Ifyouneed
topushthemachinebyhand,youmustpositionthe
leverforthedrivewheelreleasevalvetothevalve
releasedposition(Figure12).
g223057
Figure12
1.Lever—drivewheel
releasevalve(normal
operatingposition)
3.Lever—drivewheel
releasevalve(pushthe
machineposition)
2.Washeroutsideoftheslot
4.Washerinsidetheslot
(valvereleasedposition)
Toreleasethedrivewheels,movethelevertothe
largeropeningoftheslot,pushitinuntilthewasher
isinsidetheframe,thenmovetheleverbacktothe
narrowportionoftheslot.Repeatthisoneachside
ofthemachine.
Disengagetheparkingbrake.Themachineisnow
abletobepushedbyhand.
Donottowmachine.
Toresetthedrivesystembacktotheoperating
position:
Movethelevertothelargeropeningoftheslot,pull
outwarduntilthewasherisoutsidetheframe,then
movetheleverbacktothenarrowportionoftheslot.
Repeatthisoneachsideofthemachine.
