Thereare2waystoactivatethedisplay:
1.T apthemulti-functionswitcheitherupordown
todisplaythetine-engagementmeter.
2.Steponthetineground-engagementfootswitch.
Ahighernumberonthestatusbarincreasesthe
lengthoftheaerationplugandalowernumber
decreasesit.
Note:Ifthepluglengthisnotdesiredlength,the
machinemayneedtobeadjustedtoaccommodate
fortheweightoftheoperator;refertoAdjustingthe
OperatorWeightControlSetting(page24)formore
information.
LEDStatusLights
Locatedontherightsideofthehour
meter/tine-engagementdisplay.
TheLEDismulti-coloredtoindicatethesystemstatus
andislocatedontherightsideofthepanel.
•Solidgreen—indicatesnormaloperatingactivity.
•Blinkingred—indicatesafaultisactive.
•Solidred—indicatesmaintenanceisrequired.
TinesGround-EngagementFoot
Switch
Theswitchislocatedontheoperatorplatform(Figure
7).
Tolowerthetinesintotheground,standonthetine
ground-engagementswitch.TheLEDilluminatesin
thehourmeter/tineengagementdisplaywhenthetine
engagementisactivated.Toraisethetines,remove
yourfootfromtheswitch.
Thisswitchcanbedisabledwiththemulti-function
switch.
•Tapandholdthebottomoftheswitchtooverride
anddisablethefootswitch.TheLEDilluminatesin
thehourmeter/tineengagementdisplay.Usethis
featurewhentransportingthemachine.
•Tounlock,tapandholdthetopofthemulti-function
switchuntiltheLEDlightdisappears.
Note:Thedisablefeatureisengagedeachtimeyou
shutofftheengine.
KeySwitch
Thekeyswitchislocatedontherightsideofthe
controlconsole(Figure7).
Usethekeyswitchtostartandshutofftheengine.
Theswitchhas3positions:OFF,ON,andSTART
(Figure10).
g008610
Figure10
1.OFF3.START
2.ON
Multi-FunctionSwitch
Locatedtotheleftofthehourmeter/tine-engagement
display.
Thisswitchallowsyoutodothefollowing:
•Increase/decreasethedepthofanaerationplug.
•Lockorunlockthetine-depthsetting.
•Lockorunlockthetineground-engagementfoot
switch.
