InformationScreens
Themaininformationscreensinclude:
•TheStartupScreens
•TheDefaultScreen(engine-on)
•TheTineEngagementDisplay
•MaintenanceRemindersandAlerts
•AlertsandErrorMessages
Start-upScreens
WhenthekeyisswitchedfromOFFtoRUNposition,
thefollowingscreensdisplayfor2seconds:
Note:TheLEDstatuslightchangesfromredto
orangetogreen.
Therstscreendisplaysthermwareversion.
g212116
Figure14
Thesecondscreendisplaystheaerationhours.
g212114
Figure15
Thethirdscreendisplaystheelectricalsystemvoltage.
g212115
Figure16
Thefourthscreendisplaysthenumberofhoursuntil
theengineoilmaintenanceisrequired.
g212117
Figure17
Thenalscreendisplayedisthenumberofhoursuntil
transmissionoilmaintenanceisrequired.
g212118
Figure18
TheDefaultScreen
Afterthestart-upscreensdisplay,thedefaultscreen
(Figure19)appears.
Theinformationscreendisplaysiconsandinformation
relativetomachineoperation.
g211884
Figure19
DefaultScreen
1.Informationscreen
2.LEDstatuslight
•Thesafetyinterlockstatusindicatorilluminates
whenthecontrolmeetsthe“safetostart”mode
(parkbrakeengaged).
