DANGER
Jumpstartingaweakbatterythatiscracked,
frozen,haslowelectrolytelevel,oran
open/shortedbatterycell,cancausean
explosionresultinginseriouspersonalinjury.
Donotjumpstartaweakbatteryifthese
conditionsexist.
WARNING
Batteriescontainacidandproduceexplosive
gases.
•Alwaysshieldyoureyesandfacefromthe
battery.
•Donotleanoverthebatteries.
PreparingtoJumpStarttheBattery
CAUTION
Corrosionorlooseconnectionscancause
unwantedelectricalvoltagespikesatanytime
duringthejumpstartingprocedure.
DoNotattempttojumpstartwithlooseor
corrodedbatteryterminalsordamagetothe
enginemayoccur.
1.Checkthecableclampsandbatteryterminals
ofthedischargedbatteryforcorrosion(white,
green,orblue“snow”)andcheckthatthe
hardwarefortheclampsistight.
Cleancorrosionfromthebatteryterminalsand
cableclamps.
2.Checkthatthehardwareforthecableclamps
istight.
Tightenthecable-clamphardwareasneeded.
3.Checkthattheventcapsonthedischarged
batteryandboosterbatteryaretightandlevel.
4.Ifavailable,placedampclothesoverthevent
capsofbothbatteries.
5.Ifyouarejumpstartingfromthebatteryin
anothervehicle,ensurethatithasa12Vlead
acidbattery.
Important:Ensurethatthe2vehiclesdo
nottouch.
6.Ensurethattheboosterbatteryisfullycharged
with12.6voltsorgreater.
7.Selectproperlysizedjumpercables(4to6
AWG)withshortlengthstoreducevoltagedrop
betweensystems.
Choosejumpercableswithcolorcodedor
polaritylabeledcablesorclamps.
ConnectingtheJumperCables
CAUTION
Connectingthejumpercablesincorrectly
(wrongpolarity)canimmediatelydamagethe
electricalsystem.
Becertainofbatteryterminalpolarityand
jumpercablepolaritywhenhookingup
batteries.
1.Connectthepositivejumpercable—red(+)to
thepositive-batteryterminalofthedischarged
batteryasshowninFigure49.
Note:Thepositive-batteryterminaliswiredto
thestarterorsolenoid
g012785
Figure49
1.Positive(+)jumpercable
atthedischargedbattery
5.Boosterbattery
2.Positive(+)jumpercable
attheboosterbattery
6.Dischargedbattery
3.Negative(–)jumpercable
attheboosterbattery
7.Engineblock(themachine
withadischargedbattery)
4.Negative(–)jumpercable
totheengineblock(the
machinewithadischarged
battery)
2.Connecttheotherendofthepositivecable
tothepositive-batteryterminalofthebooster
battery(Figure49).
3.Connectthenegativejumpercable—black(–)
tothenegative-batteryterminalofthebooster
battery.
4.Atthemachinewithadischargedbattery,
connecttheotherendofthenegativejumper
cabletotheengineblock,atalocationaway
fromthebatteryandbelts(Figure49).
