Toro 30447N - Product Overview; Controls

ProductOverview
Controls
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
CAUTION
Thismachineproducessoundlevelsinexcessof85
dBAattheoperatorsearandcancausehearingloss
throughextendedperiodsofexposure.
Wearhearingprotectionwhenoperatingthis
machine.
TractionPedal
Tostop,reduceyourfootpressureonthetractionpedaland
allowittoreturntothecenterposition(Figure2).
Figure2
1.Brakepedals6.Fuelgauge
2.Pedallockinglatch
7.Hazardlightswitch(GM
4100only)
3.Spaceforoptional
accessory
8.Tiltsteeringlever
4.Spaceforoptional
accessory
9.Tractionpedal
5.Parkingbrakelatch
BrakePedals
TwofootpedalsFigure2operateindividualwheelbrakesfor
turningassistance,parking,andtoaidinobtainingbetterside
hilltraction.Alatchconnectsthepedalsforparkingbrake
operationandtransport.
PedalLockingLatch
ThepedallockinglatchFigure2connectsthepedalstogether
toengagetheparkingbrake.
TiltSteeringLever
PresstheleverFigure2downtotiltthesteeringwheelto
thedesiredposition.Thenreleasethelevertolockthe
adjustment.
ParkingBrakeLatch
Aknobontheleftsideoftheconsoleactuatestheparking
brakelock(Figure2).Toengagetheparkingbrake,connect
thepedalswiththelockinglatch,pushdownonbothpedals,
andpulltheparkingbrakelatchout.Toreleasetheparking
brake,pressbothpedalsuntiltheparkingbrakelatchretracts.
FuelGauge
Thefuelgauge(Figure2)indicatestheleveloffuelinthetank.
HazardLightSwitch(GM4100only)
Pressthehazardlightswitch(Figure2)toactivatethehazard
lights.
SpeedLimiter
Ifdesired,thescrewcanbeadjusted(Figure3)tolimitthe
amountthetractionpedalcanbedepressedintheforward
directiontolimitthemowingspeed.
Figure3
1.Speedlimiter
Important:Wheninthemowposition,thespeedlimiter
screwmuststopthetractionpedalbeforethepump
reachesfullstrokeordamagetothepumpmayoccur.
DiagnosticLight
Thediagnosticlight(Figure4)willilluminateshouldasystem
faultberecognized.
