Figure55
1.Waterseparatorltercanister
3.Cleantheareawheretheltercanistermounts.
4.Removetheltercanisterandcleanthemounting
surface.
5.Lubricatethegasketontheltercanisterwithcleanoil.
6.Installtheltercanisterbyhanduntilthegasket
contactsmountingsurface,thenrotateitanadditional
1/2turn.
7.Tightenthedrainplugonthebottomofthelter
canister.
BleedingAirfromtheInjectors
1.LoosenthetubeconnectiontotheNumber1injector
nozzleandholderassemblyattheinjectionpump
(Figure56).
Figure56
1.Number1injectornozzle
2.MovethethrottletotheFastposition.
3.TurnthekeyintheignitionswitchtotheStartposition
andwatchthefuelowaroundtheconnector.Turn
thekeytotheOffpositionwhensolidowisobserved.
4.Tightenthetubeconnectorsecurely.
5.Repeattheprocedureontheremainingnozzles.
ElectricalSystem
Maintenance
BatteryCare
Batterytypeisgroup24.
Important:Beforeweldingonthemachine,disconnect
thenegativecablefromthebatterytopreventdamageto
theelectricalsystem.
Note:Checkthebatteryconditionweeklyorafterevery
50hoursofoperation.Keeptheterminalsandtheentire
batterycasecleanbecauseadirtybatterywilldischargeslowly.
Tocleanthebattery,washtheentirecasewithasolution
ofbakingsodaandwater.Rinsewithclearwater.Coat
thebatterypostsandcableconnectorswithGrafo112X
(skin-over)grease(ToroPartNo.505-47)orpetroleumjelly
topreventcorrosion.
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
1.Raisetheseatandsecureitwiththeproprod.
2.Removethebatterycover(
Figure57).
Figure57
1.Batterycover
38
