Figure58
1.Battery
WARNING
Chargingthebatteryproducesgassesthatcan
explode.
Neversmokenearthebatteryandkeepsparks
andamesawayfrombattery.
3.Removetherubberbootfromthepositiveterminal
andinspectthebattery.
WARNING
Batteryterminalsormetaltoolscouldshort
againstmetalcomponentscausingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Whenremovingorinstallingthebattery,
donotallowthebatteryterminalstotouch
anymetalpartsofthemachine.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsof
themachine.
WARNING
Incorrectbatterycableroutingcoulddamage
themachineandcablescausingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Always
disconnect thenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Always connect thepositive(red)battery
cablebeforeconnectingthenegative
(black)cable.
4.CoatbothbatteryconnectionswithGrafo112X
(skin-over)grease,ToroPartNo.505-47,petroleum
jelly,orlightgreasetopreventcorrosion.Slidethe
rubberbootoverthepositiveterminal.
5.Installthebatterycover.
Fuses
Theretractionunitfuses(Figure59thruFigure61)are
locatedunderthehoodinthefusebox.
g011539
1
Figure59
1.Fusebox
G01 1542
1
2
2
10
20
7.5
7.5
10
7.5
7.5
10
7.5
7.5
10
Figure60
1.Fuses
