Figure61
1.ReadtheOperator's
Manualforfuse
information.
7.Powerpoint—10Afuse
2.Enginepreheat—60Afuse8.Instuments—10Afuse
3.Engine,start—20Afuse9.Controlmodule—2Afuse
4.Headlights—10Afuse10.Controlmodule—2Afuse
5.Turnsignal—10Afuse11.Powerpoint—7.5Afuse
6.PowerSeat—10Afuse
Note:Thecabfuses(Figure62)arelocatedinthefusebox
inthecabheadliner(model30447only).
Figure62
1.Fuses2.Fuseboxcover
40
