Toro 30488 - Adjusting the Anti-Scalp Rollers

Figure15
1.Carrierframe4.Spacers
2.Hairpincotter
5.Frontoftheheight-of-cut
post
3.Backoftheheight-of-cut
post
AdjustingtheAnti-Scalp
Rollers
Theanti-scalprollersneedtobeadjustedintheproperhole
locationforeachheight-of-cutposition.Thereneedstobe10
mm(3/8inch)minimumclearanceabovetheground.
Note:Iftheanti-scalprollersareadjustedtoolow,itcan
causeexcesswearoftherollers.
1.Afteradjustingheight-of-cut,checktheanti-scalp
rollerssothatthereisaminimumof10mm(3/8
inch)clearanceabovetheground(Figure16,Figure
17,Figure18).
2.Ifadjustmentisneeded,removethebolt,washers,and
nut(Figure16,Figure17,Figure18).
3.Selectaholeposition,sotheanti-scalprollersarea
minimumof10mm(3/8inch)offtheground(Figure
16,Figure17,Figure18).
4.Installtheboltandnut(Figure16,Figure17,Figure
18).
Figure16
40inch,48inch,and52inchMowerDecks
1.Mowerdeck4.Anti-scalprollers
2.Bolt5.Nut
3.Spacer
Figure17
40inch,48inch,and52inchMowerDecks
1.Mowerdeck4.Bushing
2.Bolt5.Anti-scalprollers
3.Spacer
6.Nut
21
