Toro 30488 - Changing the Mower Deck Front-To-Rear Pitch; Checking the Mower Deck Side-To-Side Height

ChangingtheMowerDeck
Front-to-RearPitch
Changingthefront-to-rearpitchisdonebyadjustingthe
frontheight-of-cutposts.
1.Tochangethefront-to-rearpitch,thefront
height-of-cutpostscanbeadjusted(Figure72).
Figure72
1.Casterwheel
4.Jamnut
2.Carrierframe
5.Balljoint
3.Frontheight-of-cutpins
2.Toraisethefrontofthedeck,loosenthejamnutand
rotatethefrontpinclockwise(Figure72).
3.Tolowerthefrontofthedeck,loosenthejamnutand
rotatethefrontpincounterclockwise(Figure72).
4.Positionthebladesfront-to-rear.
5.MeasureattheCandDlocations(Figure71)froma
levelsurfacetothecuttingedgeoftheblades.
6.Checktheside-to-sidelevelingofthecuttingunit.
7.Tightenthejamnuts(Figure72).
CheckingtheMowerDeck
Side-to-SideHeight
1.Adjustthereartirepressuretospecications;referto
CheckingtheTirePressure(page34).
2.Positionthebladesside-to-side.
3.MeasureatCandDlocationsfromalevelsurfaceto
thecuttingedgeofbladetips(Figure73).
Figure73
1.Measurefromalevel
surface
2.MeasurebladeatpointsC
andD
4.ThedifferencebetweenmeasurementsCandDshould
benomorethan6mm(1/4inch).
50
