ChargingtheBattery
WARNING
Chargingthebatteryproducesgassesthatcan
explode.
Neversmokenearthebatteryandkeepsparksand
amesawayfrombattery.
Important:Alwayskeepthebatteryfullycharged
(1.265specicgravity).Thisisespeciallyimportantto
preventbatterydamagewhenthetemperatureisbelow
0°C(32°F).
1.Removethebatteryfromthechassis;refertoRemoving
theBattery(page31).
2.Checktheelectrolytelevel;refertoCheckingthe
Battery-ElectrolyteLevel(page32).
3.Makesurethatthellercapsareinstalledinbattery.
4.Chargethebatteryfor1hourat25to30ampsor6
hoursat4to6amps.
5.Whenthebatteryisfullycharged,unplugthecharger
fromtheelectricaloutlet,thendisconnectthecharger
leadsfromthebatteryposts(Figure40).
6.Installthebatteryontothemachineandconnectthe
batterycables.
Note:Donotrunthemachinewiththebattery
disconnected,electricaldamagemayoccur.
Figure40
1.Positivebatterypost
3.Red(+)chargerlead
2.Negativebatterypost
4.Black(-)chargerlead
ServicingtheFuses
Theelectricalsystemisprotectedbyfuses.Itrequiresno
maintenance.Ifafuseblows,checkthecomponentorcircuit
foramalfunctionorshort.
1.Removethecoverunderthecontrolpanel.
2.Pulloutonthefusetoremoveorreplaceit(Figure41).
3.Installthecoverunderthecontrolpanel.
Note:Ensurethatthecorrect-sizefuseisinstallwith
thecorrectwirecolorasshowninFigure41.
Figure41
1.Redwire3.Fuse—25amp,bladetype
2.Fuse—30amp,bladetype4.Violetwire
33
