Toro 30488 - Adding Water to the Battery

g012916
7
6
5
4
3
2
1
8
9
10
11
Figure38
1.J-bolt7.Wingnut
2.Positivecable8.Negativecable
3.Washer
9.Rubbercover(black)
4.Nut(5/16inch)
10.Bolt
5.Rubbercover(red)
11.Battery
6.Batteryholddown
CheckingtheBattery-ElectrolyteLevel
ServiceInterval:Every25hours
DANGER
Batteryelectrolytecontainssulfuricacidwhichisa
deadlypoisonandcausessevereburns.
•Donotdrinkelectrolyteandavoidcontactwith
skin,eyesorclothing.Wearsafetyglassesto
shieldyoureyesandrubberglovestoprotect
yourhands.
•Fillthebatterywherecleanwaterisalways
availableforushingtheskin.
1.Lookatthesideofthebattery.Theelectrolytemust
beuptotheupperline(Figure39).Donotallowthe
electrolytetofallbelowtheLowerline(Figure39).
Figure39
1.Ventcaps3.Lowerline
2.Upperline
2.Iftheelectrolyteislow,addtherequiredamountof
distilledwater;refertoAddingWatertotheBattery
(page32).
AddingWatertotheBattery
Thebesttimetoadddistilledwatertothebatteryisjust
beforeyouoperatethemachine.Thisletsthewatermix
thoroughlywiththeelectrolytesolution.
1.Removethebatteryfromthemachine;referto
RemovingtheBattery(page31).
Important:Neverllthebatterywithdistilled
waterwhilethebatteryisinstalledinthemachine.
Electrolytecouldbespilledonotherpartsand
causecorrosion.
2.Cleanthetopofthebatterywithapapertowel.
3.Removetheventcapsfromthebattery(Figure39).
4.Slowlypourdistilledwaterintoeachbatterycelluntil
theelectrolytelevelisuptotheUpperline(Figure39)
onthebatterycase.
Important:Donotoverllthebatterybecause
electrolyte(sulfuricacid)cancausesevere
corrosionanddamagetothechassis.
5.Waitfor5to10minutesafterllingthebatterycells.
6.Adddistilledwater,ifnecessary,untiltheelectrolyte
levelisuptotheUpperline(Figure39)onthebattery
case.
7.Installthebattery-ventcaps.
