3.Measurecarrier-frameheightatlocationB(Figure69).
4.TheheightatlocationAmustbe3to10mm(1/8inch
to3/8inch)lowerthanlocationB(Figure69).
5.Ifthecarrierframeisnotcorrect,movecasterspacers
tomakeitan3to10mm(1/8inchto3/8inch)pitch
(Figure69).
6.Movespacersfromthetoporbottomtomakethe
correctpitch.
7.Thetirepressuremayalsobeadjustedslightlytomake
an3to10mm(1/8inchto3/8inch)pitch.
CheckingtheCarrierFrame
Side-to-SideHeight
Thecarrierframeneedstobeparallelside-to-sidefromthe
ground.
1.DisengagethePTOandsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
3.Adjustthetirepressureinthereartirestospecications;
refertoCheckingtheTirePressure(page34).
4.Measurecarrier-frameheightatlocationA(Figure70).
5.Measurecarrier-frameheightatlocationB(Figure70).
6.Ifthecarrier-frameheightisnotthesamemovespacers
fromthetoporbottomofcasterwheel,tomakeit
level.Thetirepressuremayalsobeadjustedslightly
tomakeitlevel.
Figure70
1.Casterwheel4.Sameheightatlocations
AandB
2.Carrierframe5.Casterspacers
3.Frontheight-of-cutpins
CheckingtheMowerDeck
Front-to-RearPitch
1.Adjustthetirepressureinthereartirestospecications;
refertoCheckingtheTirePressure(page34).
2.Positiononebladefront-to-rear.MeasureatAandB
locationsfromalevelsurfacetothecuttingedgeof
thebladetips(Figure71).
3.Themowerbladeshouldbea6mm(1/4inch)lower
inthefrontatAthanintherearatB.
4.Rotatebladesandrepeatforotherblades.Ifitis
notcorrect,proceedtoChangingtheMowerDeck
Front-to-RearPitch(page50).
Figure71
1.MeasurebladeatpointsA
andB
2.Measurefromalevel
surface
