Toro 30488 - Using the MID-Size Weight

PositionC
Thisisthefullopenposition.Thesuggesteduseforthis
positionisasfollows(Figure22).
•Useintall,densegrassmowingconditions.
•Useinwetconditions.
•Lowerstheenginepowerconsumption.
•Allowsincreasedgroundspeedinheavyconditions.
G012679
Figure22
UsingtheMid-SizeWeight
Weightsareinstalledoncertainmowerstoimprovebalance
andimproveperformance.Theweightscanbemovedor
removedtocreateoptimizedperformanceunderdifferent
mowingconditionsandforoperatorpreference(Figure23
orFigure24).
Thefollowingtableindicatesthepositionoftheweightas
installedatthefactory.
MowerDeckSizeNumberof
weightsinstall
Positionofthe
weight
48inches
nonenone
52inches1Rear
•AnyrearweightmustberemovedwhenaTru–Track
®
Sulkyisinstalled.
•WhenaTru-Track
®
Sulkyisinstalled,frontweightsare
needed.ContactanAuthorizedServiceDealerforthe
correctquantityofweightsandplacement.
WARNING
Thefrontendofthemachinecanrapidlyriseup
whenthemowerisremoved.Thiscouldcause
seriousinjurytoyouorbystanders.
Supporttherearofthemachinewhenremovingthe
mowerfromthecarrierframe.
Figure23
Installingthefrontweight
1.Bolt3.Weight
2.Washer4.Nut
Figure24
Installingtherearweight
1.Nut3.Washer
2.Weight4.Bolt
23
