Figure7
1.Safetyinterlocksymbols
3.Hourmeter
2.Batterylight
ThrottleControl
ThethrottlecontrolisvariablebetweenFastandSlow.
Choke
Usethechoketostartacoldengine.
BladeControlSwitch(PTO)
Thebladecontrolswitch(PTO)isusedtoengagetheelectric
clutchtodrivethemowerbladeswiththerightsidemotion
controlleverinthecenter,un-lockedposition.Pullthe
switchuptoengagethebladesandrelease.Todisengagethe
blades,pushthebladecontrolswitch(PTO)downormove
orreleasetherightsidemotioncontrolleverintotheneutral
lockposition.
IgnitionSwitch
Thisswitchisusedtostartthemowerengineandhasthree
positions:Off,RunandStart.
MotionControlLevers
Themotioncontrolleversareusedtodrivethemachine
forward,reverse,andturneitherdirection.
FuelShut-offValve
Closethefuelshut-offvalve(locatedbehindtheoperator
cushionontherighthandsideofthefueltank)when
transportingorstoringthemower.
Attachments/Accessories
AselectionofToroapprovedattachmentsandaccessoriesare
availableforusewiththemachinetoenhanceandexpand
itscapabilities.ContactyourAuthorizedServiceDealeror
Distributororgotowww.Toro.comforalistofallapproved
attachmentsandaccessories.
Specications
Note:Specicationsanddesignaresubjecttochange
withoutnotice.
48inchmowers:
Widthwithdeectordown63.5inches(161.3cm)
Widthwithdeectorraised49.5inches(125.7cm)
Lengthwithplatformdown74inches(188cm)
Lengthwithplatformup59inches(149.9cm)
Height
48inches(121.9cm)
Weightformodel74578897lbs(406.9kg)
Weightformodel79548903lbs(409.6kg)
52inchmowers:
Widthwithdeectordown67.6inches(171.7cm)
Widthwithdeectorraised53.5inches(135.9cm)
Lengthwithplatformdown74inches(188cm)
Lengthwithplatformup59inches(149.9cm)
Height
48inches(121.9cm)
Weightformodel74549908lbs(411.9kg)
Weightformodel79549914lbs(414.6kg)
60inchmowers:
Widthwithdeectordown75.6inches(192.0cm)
Widthwithdeectorraised61.5inches(156.2cm)
Lengthwithplatformdown77.9inches(197.9cm)
Lengthwithplatformup62.9inches(159.8cm)
Height
48inches(121.9cm)
Weightformodel74553924lbs(419.1kg)
Weightformodel79553930lbs(421.8kg)
