Toro 74549 - Deck Lift and Height Matching; Matching Height of Cut; Deck Lift Spring Adjustment

G015501
1
2
3
4
Figure91
60inchmowerdecks
1.Adjustmentrods
3.Liftlink
2.Rearnuts4.Frontnuts
MatchingHeightofCut
1.Checkthereartirepressure.
2.Settheheight-of-cuttothe3inch(7.6cm)position.
RefertoAdjustingtheHeight-Of-CutinOperation.
3.Withthemachineonlevelsurface,positiononeblade
front-to-rear.MeasureatAandfromlevelsurfaceto
thecuttingedgeofthebladetips(Figure92).
Figure92
1.Measurefromalevel
surface
2.MeasurebladeatpointA
4.Themeasurementshouldbe3inch(7.6cm).
5.Ifitdoesnotmeasurecorrectly,locatetheheight-of-cut
rodontherightsideofthemachine(
Figure93).
6.Adjusttheadjustmentboltuntilthebladetipsmatch3
inches(7.6cm)(Figure93).
g015336
1
2
Figure93
1.Height-of-cutrod
2.Adjustmentbolt
AdjustingtheDeckLiftSpring
Note:Adjustingthedeckliftspringwillalterhowmuchthe
deckwilloatandhowmucheffortittakestoliftthedeck
whenusingtheheight-of-cuthandle.
1.Raisethedeckliftleverandlockintothetransport
position.
2.Checkthelengthbetweenthespringnutandthe
bottomoftheweldedU-bracket(
Figure94).Nominal
lengthisbetween1.84to1.96inches(47.0to50.0mm)
for48and52inchmowerdecksandbetween1.69to
1.81inches(43.0to46.0cm)for60inchmowerdecks
(Figure94).
57
