Toro 74549 - Transporting and Loading Machines

2.Opentheby-passvalveonbothpumpsbyturning
themcounterclockwise1to2turns.Thisallows
hydraulicuidtoby-passthepumpsandthewheels
toturn(Figure25).
Note:Rotatetheby-passvalvesamaximumof2turns
sothevalvedoesnotcomeoutofthebodycausing
uidtorunout.
Figure25
1.Pumpby-passvalve
3.Releasetheparkingbrake.
4.Pushthemachinetothedesiredlocation.
5.Settheparkingbrake.
6.Closetheby-passvalves,butdonotovertightenthem.
Torqueto110to130in-lb(12to15N-m).
Important:Donotstartoroperatethemachine
withtheby-passvalvesopen.Damagetosystem
mayoccur.
TransportingMachines
Useaheavy-dutytrailerortrucktotransportthemachine.
Ensurethatthetrailerortruckhasallnecessarybrakes,
lighting,andmarkingasrequiredbylaw.Pleasecarefullyread
allthesafetyinstructions.Knowingthisinformationcould
helpyou,yourfamily,petsorbystandersavoidinjury.
Totransportthemachine:
1.Raisetheplatformofthemachinebeforedrivingup
ontothetrailerortruck.
2.Ifusingatrailer,connectittothetowingvehicleand
connectthesafetychains.
3.Ifapplicable,connectthetrailerbrakes.
4.Loadthemachineontothetrailerortruck.
5.Stoptheengine,removethekey,setthebrake,and
closethefuelvalve.
6.Usethemetaltiedownloopsonthemachineto
securelyfastenthemachinetothetrailerortruckwith
straps,chains,cable,orropes(Figure26).
G015235
Figure26
1.Tractionunittiedownloop
LoadingMachines
Useextremecautionwhenloadingunitsontrailersortrucks.
Onefullwidthrampthatiswideenoughtoextendbeyond
thereartiresisrecommendedinsteadofindividualramps
foreachsideoftheunit(Figure27).Theplatformwhen
downandlockedintoposition,extendsbackbetweentherear
wheelsandservesasastopfortippingbackward.Havinga
fullwidthrampprovidesasurfacefortheplatformtocontact
iftheunitstartstotipbackward.Withtheplatformup,a
fullwidthrampprovidesasurfacetowalkonbehindthe
unit.Theoperatorshoulddetermineifitisbesttohavethe
platformupordownwhenloading,dependingonconditions.
Ifitisnotpossibletouseonefullwidthramp,useenough
individualrampstosimulateafullwidthcontinuousramp.
Therampshouldbelongenoughsothattheanglesdonot
exceed20degrees(
Figure27).Asteeperanglemaycause
mowercomponentstogetcaughtastheunitmovesfrom
ramptotrailerortruck.Steeperanglesmayalsocausethe
unittotipbackward.Ifloadingonornearaslope,position
thetrailerortrucksoitisonthedownsideoftheslopeand
therampextendsuptheslope.Thiswillminimizetheramp
angle.Thetrailerortruckshouldbeaslevelaspossible.
Important:DoNotattempttoturntheunitwhileon
theramp;youmaylosecontrolanddriveofftheside.
Avoidsuddenaccelerationwhendrivinguparampand
suddendecelerationwhenbackingdownaramp.Both
maneuverscancausetheunittotipbackward.
23
