Toro 74549 - Pump Drive Belt Replacement

G015595
Figure68
48and52inchmowerdecks
1.6-1/2inches(165mm)
fromhooktohook
4.Ratchet
2.Spring5.Squareholeforratchet
3.Springloadedidler
6.Nut
6 5
g017890
Figure69
60inchmowerdecks
1.6-1/2inches(165mm)
fromhooktohook
4.Ratchet
2.Spring5.Squareholeforratchet
3.Springloadedidler
6.Nut
ReplacingthePumpDriveBelt
ServiceInterval:Every100hours—Checkthepumpdrive
belt.
1.DisengagethePTOandsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
3.Removethemowerdeckbelt.
4.Tiltthemachineonit'sback.RefertoPre-Maintenance
atthebeginningoftheMaintenanceSection.
5.Removetheshoulderbolt,nutandwasherfromthe
enginedeckandconnectedtothespring(Figure70).
46
