DrivingBackward
1.Movetherightsidemotioncontrollevertothecenter,
un-lockedposition.
2.Slowlypullthemotioncontrolleversrearward
(Figure23).
Figure23
StoppingtheMachine
Tostopthemachine,movethemotioncontrolleversto
neutral,movetherightsidemotioncontrolleverintothe
neutrallockposition,disengagethepowertakeoff(PTO),
andturntheignitionkeytooff.
Settheparkingbrakewhenyouleavethemachine;referto
SettingtheParkingBrakeinOperation.Remembertoremove
thekeyfromtheignitionswitch.
CAUTION
Childrenorbystandersmaybeinjuredifthey
moveorattempttooperatethetractorwhileitis
unattended.
Alwaysremovetheignitionkeyandsettheparking
brakewhenleavingthemachineunattended,even
ifjustforafewminutes.
UsingtheRotationIndicator
Theslotsinthetopofthebeltcoversallowtheoperatorto
verifyifthebladeshavestoppedrotatingafterdisengagingthe
powertake-off(PTO)switch.
Disengagethepowertake-off(PTO)switch,stoptheengine,
removethekey,andwaitforallmovingpartstostopbefore
leavingtheoperatingposition.
G017978
1
1 2
1
Figure24
52inchmowerdeckshown
1.RotationIndicator-slotsin
thetopofthebeltcover
2.Sidedischargechute
PushingtheMachinebyHand
Theby-passvalvesallowthemachinetobepushedbyhand
withouttheenginerunning.
Important:Alwayspushthemachinebyhand.Never
towthemachinebecausehydraulicdamagemayoccur.
ToPushtheMachine
1.DisengagethePTO,movethemotioncontrolleversto
theneutrallockedpositionandsettheparkingbrake.
