Toro Groundsmaster 4010-D - 1 Greasing the Machine; 2 Replacing the Warning Decal; Setup

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Nopartsrequired
–
Greasethemachine.
2
WarningDecal1
Usedonlyonmachinesrequiring
EuropeanCEcompliance.
MediaandAdditionalParts
Description
Qty.
Use
Operator'sManual
1
Reviewbeforeoperatingmachine
EngineOperator'sManual
1
Usetoreferenceengineinformation
PartsCatalog
1
Usetoreferencepartnumbers
OperatorTrainingMaterials
1
Reviewbeforeoperatingmachine
Declarationofconformity
1
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
1
GreasingtheMachine
NoPartsRequired
Procedure
Beforethemachineisoperated,itmustbegreasedtoensure
properlubricatingcharacteristics;refertoGreasingthe
BearingsandBushingsinLubrication.Failuretoproperly
greasethemachinewillresultinprematurefailureofcritical
parts.
2
ReplacingtheWarningDecal
Partsneededforthisprocedure:
1WarningDecal
Procedure
OnmachinesrequiringEuropeanCEcompliance,replace
thewarningdecal,partno.117–2754withthewarningdecal
partno.117–2766.
