ProductOverview
Controls
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
CAUTION
Thismachineproducessoundlevelsinexcessof85
dBAattheoperatorsearandcancausehearingloss
throughextendedperiodsofexposure.
Wearhearingprotectionwhenoperatingthis
machine.
TractionPedal
Tostop,reduceyourfootpressureonthetractionpedaland
allowittoreturntothecenterposition(
Figure3).
9
10
g020756
Figure3
1.Brakepedals6.Hazardlightswitch
2.Pedallockinglatch7.Turnsignalswitch
3.Parkingbrakelatch
8.Hornbutton(optional)
4.Spaceforoptional
accessory
9.Tractionpedal
5.Beaconswitch(optional)
10.Tiltsteeringlever
BrakePedals
Twofootpedals(Figure3)operateindividualwheelbrakes
forturningassistance,parking,andtoaidinobtainingbetter
sidehilltraction.Alatchconnectsthepedalsforparking
brakeoperationandtransport.
PedalLockingLatch
Thepedallockinglatch(Figure3)connectsthepedals
togethertoengagetheparkingbrake.
TiltSteeringLever
Pressthelever(Figure3)downtotiltthesteeringwheel
tothedesiredposition.Thenreleasethelevertolockthe
adjustment.
ParkingBrakeLatch
Aknobontheleftsideoftheconsoleactuatestheparking
brakelock(Figure3).Toengagetheparkingbrake,connect
thepedalswiththelockinglatch,pushdownonbothpedals,
andpulltheparkingbrakelatchout.Toreleasetheparking
brake,pressbothpedalsuntiltheparkingbrakelatchretracts.
HazardLightSwitch
Pressthehazardlightswitch(Figure3)toactivatethehazard
lights.
TurnSignalSwitch
Presstheleftsideoftheturnsignalswitch(Figure3)to
activatetheleftturnsignalandtherightsideoftheswitchto
activatetherightturnsignal.Thecenterpositionisoff.
KeySwitch
Thekeyswitch(Figure4)hasthreepositions:Off,
On/Preheat,andStart.
g020513
1
2
3
4
5
6
7
8
Figure4
1.Liftswitches
5.Hi-Lospeedcontrol
2.PTOswitch
6.Enginespeedswitch
3.Keyswitch
7.Lightswitch(optional)
4.InfoCenter8.Cruisecontrolswitch
EngineSpeedSwitch
Theenginespeedswitch(Figure4)hastwomodestochange
theenginespeed.Bymomentarilytappingtheswitch,the
enginespeedcanbeincreasedordecreasedin100rpm
increments.Byholdingtheswitchdowntheenginewill
16
