Figure53

1.Waterseparatorltercanister

3.Cleantheareawheretheltercanistermounts.

4.Removetheltercanisterandcleanthemounting

surface.

5.Lubricatethegasketontheltercanisterwithcleanoil.

6.Installtheltercanisterbyhanduntilthegasket

contactsmountingsurface,thenrotateitanadditional

1/2turn.

7.Tightenthedrainplugonthebottomofthelter

canisterandclosetheventonthetopofthecanister

mount.

ServicingtheEngineFuel

Filter

ServiceInterval:Every400hours

Theenginefuelltershouldbereplacedafterevery400

hoursofoperation.

1.Cleantheareaaroundthefuellterhead(Figure54).

Figure54

1.FuelFilterhead2.FuelFilter

2.Removethelterandcleanthelterheadmounting

surface(

Figure54).

3.Lubricatetheltergasketwithcleanlubricatingengine

oil.RefertotheEngineOperator'sManual,included

withthemachine,foradditionalinformation.

4.Installthedryltercanister,byhand,untilthegasket

contactsthelterhead,thenrotateitanadditional

1/2turn.

5.Starttheengineandcheckforfuelleaksaroundthe

lterhead.
