StartingandStoppingthe
Engine
Important:Thefuelsystemwillautomaticallybleed
itselfwhenanyofthefollowingsituationsoccur:
Initialstartupofanewmachine.
Theenginehasceasedrunningduetolackoffuel.
Maintenancehasbeenperformeduponthefuelsystem
components.
1.Ensurethattheparkingbrakeisset.Removeyourfoot
fromthetractionpedalandensurethatitisinneutral.
2.TurntheignitionkeytotheRunposition.
3.Whentheglowindicatordims,turntheignitionkey
totheStartposition.Releasethekeyimmediately
whentheenginestartsandallowittoreturntothe
Runposition.Allowenginetowarmupatmidspeed
(withoutload),thenmovethethrottlecontroltothe
desiredposition.
Important:Donotrunthestartermotormore
than30secondsatatimeorprematurestarter
failuremayresult.Iftheenginefailstostart
after30seconds,turnthekeytotheOffposition,
recheckthecontrolsandprocedures,wait30
additionalseconds,andrepeatthestarting
procedure.
4.Tostoptheengine,movethePTOswitchtotheOff
position,settheparkingbrake,returnthethrottle
settingtolowidleandrotatetheignitionkeytoOff.
Removethekeyfromtheswitchtopreventaccidental
starting.
Important:Allowenginetoidlefor5minutesbefore
shuttingitoffafterafullloadoperation.Failuretodo
somayleadtoturbo-chargertrouble.
SmartPower
WithToroSmartPower™,theoperatordoesnothave
tolistentotheenginespeedinheavyconditions.Smart
Powerpreventsboggingdowninheavyturfbyautomatically
controllingthemachinespeedandoptimizingcutting
performance.Theoperatorcansimplysetamaxground
speed,thatiscomfortable,andmowwithouthavingto
manuallyreducethetractionspeedwhenmowinginheavy
conditions.
ReversingFanOperation
Thefanspeediscontrolledbyhydraulicoiltemperatureand
enginecoolanttemperature.Areversecycleisautomatically
initiatedwheneithertheenginecoolantorhydraulicoil
temperaturereachesacertainpoint.Thisreversalwillhelp
blowdebrisofftherearscreenandlowertheengineand
hydraulicoiltemperatures.Bysimultaneouslypressingthe
rightandleftbuttonsontheInfoCenter,thefanwillcomplete
amanuallyinitiatedreversecycle.Itisrecommendedto
manuallyreversethefanpriortoleavingtheworkarea,
enteringtheshoporstoragearea.
AutoIdle
Themachineisequippedwithautoidlewhichautomatically
idlestheenginewhenallofthefollowingfunctionsare
notused,forapredeterminedtime,previouslysetinthe
InfoCenter.
Thetractionpedalisreturnedtotheneutralposition
ThePTOisdisengaged
Noneoftheliftswitchesareactivated
Whenanyoftheabovefunctionsareinitiated,the
machinewillautomaticallyreturntothepreviousthrottle
position.
CruiseControl
Thecruisecontrolswitchlocksinthepedalpositionto
maintainthedesiredgroundspeed.Pressingtherearofthe
switchturnsoffthecruisecontrol,themiddlepositionofthe
switchenablesthecruisecontrolfunctionandthefrontof
theswitchsetsthedesiredgroundspeed.
Note:Pressingeitherbrakepedalormovingthetraction
pedalintothereverseposition,foronesecond,willalso
disengagethepedalposition.
EngineSpeedSwitch
Theenginespeedswitchhastwomodestochangetheengine
speed.Bymomentarilytappingtheswitch,theenginespeed
canbeincreasedordecreasedin100rpmincrements.By
holdingtheswitchdowntheenginewillautomaticallymove
toHighorLowidle,dependingonwhichoftheswitchis
depressed.
MowSpeed
Supervisor(ProtectedMenu)
Allowsthesupervisortosetthemachine’smaximummowing
speed,inincrementsof50%,75%or100%,atwhichthe
operatorcanmow(lowrange).
RefertoUsingtheInfoCenterLCDDisplay,intheOperation
sectionofthismanual,fortheproceduretosetthemow
speed.
Operator
Allowstheoperatortoadjustthemachine’smaximummowing
speed(lowrange),withinthesupervisorspre-adjusted
settings.WhenintheInfoCentersplashormainscreen,press
themiddlebutton(icon)toadjustthespeed.
Note:Whenswitchingbetweenlowandhighranges,the
settingswilltransferbasedontheprevioussetting.The
settingsareresetwhenthemachineisturnedoff.
32
