Figure69
1.Brakecableadjustingnuts
C.Tightentherearnuttomovethecablebackward
untilthebrakepedalshave13to25mm(1/2to1
inch)offreetravel.
D.Tightenthefrontnutsafterthebrakesareadjusted
correctly.
E.Reinstallthebrakeadjustmentcover.
BeltMaintenance
ServicingtheAlternatorBelt
ServiceInterval:Aftertherst10hours
Every100hours
Checktheconditionandtensionofthebelt(Figure70)after
every100operatinghours.
1.Propertensionwillallow10mm(3/8inch)deection
whenaforceof44N(10lb)isappliedonthebelt
midwaybetweenthepulleys.
2.Ifthedeectionisnot10mm(3/8inch),loosenthe
alternatormountingbolts(Figure70).Increaseor
decreasethealternatorbelttensionandtightenthe
bolts.Checkthedeectionofthebeltagaintoensure
thatthetensioniscorrect.
Figure70
1.Alternator
3.Compressor
2.Mountingbolt4.Idlerpulley
ServicingtheCompressorBelt
ServiceInterval:Aftertherst10hours
Every100hours
Cabmodelonly
Checktheconditionandtensionofthebelt(Figure70)after
every100operatinghours.
1.Propertensionwillallow10mm(3/8inch)deection
whenaforceof44N(10lb)isappliedonthebelt
midwaybetweenthepulleys.
2.Ifthedeectionisnot10mm(3/8inch),loosenthe
idlerpulleymountingbolt(
Figure70).Increaseor
decreasethecompressorbelttensionandtightenthe
bolt.Checkthedeectionofthebeltagaintoensure
thatthetensioniscorrect.
49
