GEAR DRIVE SYSTEM
5-16 GT Series Tractors Service Manual
5
28. Repeat step 28 to remove the opposite wheel hub
assembly.
29. Remove the nut securing the transmission pulley to
the transmission (Fig. 482).
1. Position the transmission pulley onto the trans-
mission (Fig. 484).
Fig 482 PICT-7682
Fig 484 PICT-7684
2. Install the nut securing the transmission pulley to the
transmission (Fig. 485).
30. Remove the transmission pulley (Fig. 483).
Fig 485 PICT-7682
Fig 483 PICT-7684
CVT Transmission Installation
