GEAR DRIVE SYSTEM
5-25GT Series Tractors Service Manual
5
11. Remove the washers from the input shaft (Fig. 518). 13. Remove the washer from the input shaft (Fig. 520).
Fig 518 PICT-8288 Fig 520 PICT-8290a
14. Remove the snap ring that secures the bevel gear to
the input shaft (Fig. 521).
12. Remove the input shaft assembly from the housing
(Fig. 519).
Fig 521 PICT-8293aFig 519 PICT-8289
