GEAR DRIVE SYSTEM
5-50 GT Series Tractors Service Manual
5
3. Install the puck into the brake assembly (Fig. 617).
Fig 617 PICT-7721
4. Hook the brake assembly onto the spring (Fig. 618).
Fig 618 PICT-7727
5. Insert 2 bolts into the brake assembly (Fig. 619).
Fig 619 PICT-7728
6. If washers are present, slide a washer onto each of
the bolts (Fig. 620).
Fig 620 PICT-7730
