HYDROSTATIC DRIVE SYSTEM
6-26 GT Series Tractors Service Manual
6
11. Remove the disc brake from the transmission (Fig.
728).
Fig 728 PICT-7742a
12. Remove the puck from the transmission housing
(Fig. 729).
Fig 729 PICT-7743a
9. Remove the brake assembly from the spring (Fig.
726).
Fig 726 PICT-7739
10. Remove the puck from the brake assembly (Fig.
727).
Fig 727 PICT-7741a
