MOWER DECK
7-45GT Series Tractors Service Manual
7
54” Mower Deck Spring Loaded Idler
Replacement
54” Mower Deck Spring Loaded Idler
Removal
17. Apply grease to the spindle until it begins to appear
at the weep hole (Fig. 896).
1. Remove the mower deck from the tractor. Refer to
“54” Mower Deck Removal” on page 7-29.
2. Remove the mower deck belt form the mower deck.
Refer to “54” Mower Deck Belt Removal” on page
7-23.
3. Remove the bolt, washer and nut securing the idler
pulley to the idler bracket (Fig. 897).
Fig 896 PICT-7923
Fig 897 PICT-7853
To Next Page
