ControlInterlockRemoval(continued)
Figure21
3.RemovetheshoulderscrewundertheRHhandgrip.Whenremoved,the
lockoutlatch,extensionspring,atwasher,andlocknutwilldropout.
Figure22
4.Toremovethelockoutrod,gototheRHend.Thereare2rollpinsonthe
LHsideand1inthelockoutcamontheRHside.
