WheelClutchReassembly(continued)
3.Clamporholdthegearandturnitovertoproperlyinstallthe3pawlsupports
andtorxscrews.
4.TorquetheT-27torxscrewsto100–125in-lbs.(11.3–14.1Nm).
5.Installthe4guidecollarstotheshaftwiththeshiftbraceplate.
Figure75
6.Torquethescrewsto50–70in-lbs.(5.65–7.9Nm).
7.Slidetheatwashersintopositionnexttotheguides.
8.InstalltheRIGHTandLEFTcollarintoposition.
Note:Thetopangesoftheshiftcollarshave“left”and“right”stamped
intothem.Installaccordinglyontherightandleftendsoftheshaftwiththe
shiftbraceplateorientedasshown.
Figure76
9.Installthecompressionspringsunderthepawls.
10.Slidethethrustwasherontothe32–toothsprocket.
