Workman GTX Electric Lithium Page 3B -- 39 Electrical System
USB Charge Port
The USB charge port can be used to charge or power
electrical devices that use a USB port. The charge port
has a 5 VDC output and is mounted to the dash (Fig. 39).
If the vehicle wire harness is to be disconnected from the
charge port, note the wire harness connections at the
charge port for assembly purposes. The white wire har-
ness lead should be connected to the positive (+) termi-
nal on the charge port and the black wire harness lead
should be connected to the negative (--) t erminal on the
charge port (Fig. 40).
Figure 39
1. Dash panel 2. USB charge port
1
2
1. Positive (+) terminal 2. Negative (--) terminal
Figure 40
2
1
WIRE HARNESS
USB CHARGE PORT
CONNECTIONS
Electrical
System
