Workman GTX ElectricPage 5 -- 14Chassis
Rear Wheels and Hubs
1. Rear wheel assembly
2. Lug nut (4 per wheel)
3. Transaxle assembly
4. Rear swing arm
5. Socket head screw (2 per caliper)
6. Parking brake cable (2 used)
7. Rear brake line
8. LH brake caliper
9. RH brake caliper
10. Cotter pin
11. Slotted hex nut
12. Thrust washer
13. Wheel hub
14. Hardened spacer
15. Brake rotor
16. Socket head screw (4 per rotor)
17. Wheel stud (4 per hub)
Figure 12
FRONT
RIGHT
Antiseize
Lubricant
2
3
6
8
9
10
1
2
5
7
4
35 to 40 ft
−
lb
(48 to 54 N
−
m)
11
12
13
14
15
16
220 to 240 ft
−
lb
(299 to 325 N
−
m)
220 to 240 ft
−
lb
(299 to 325 N
−
m)
9to11ft
−
lb
(13 to 14 N
−
m)
17
10
11
12
13
17
75 to 95 ft
−
lb
(102 to 128 N
−
m)
Medium Strength
Thread Locker
1
Lifted suspension
models
