Workman GTX Electric
Electrical Drawings
Page 6 -- 2
Electrical Drawing Designations
The following abbreviations are used for wire harness
colors on the electrical schematics and wire harness
drawings in this chapter.
ABBREVIATION
COLOR
BK BLACK
BN BROWN
BU BLUE
GN GREEN
GY GRAY
OR ORANGE
PK PINK
RorRD RED
TTAN
VIO VIOLET
WorWH WHITE
YorYE YELLOW
Numerous harness wires used on Workman GTX Elec-
tric vehicles include a line with an alternate color. These
wires are identified with the wire color and line color with
a / separating the color abbreviations listed above (e.g.
BK/W is a black wire with a white line).
NOTE: The wire harness d iagram in this chapter identi-
fies both the wire color and the wire gauge. For example,
16 BK on a harness diagram identifies a 16 gauge wire
that has a black insulator.
NOTE: A splice used in a wire harness will be identified
on the wire harness diagram by SP. The manufacturing
number of the splice is also identified on the wire har-
ness diagram (e.g. SP01 is splice number 1).
