Workman GTX Electric
Page 3A -- 6
Electrical System
Hand Pump Hose Assembly
Use the hand pump hose assembly when adding dis-
tilled water to vehicle batteries through the single port fill
system. The hand pump hose coupler attaches to the fill
port coupler on the Workman vehicle.
Toro Part Number: 131--8522
Figure 6
30 inch Tube 30 inch Tube
Hand
Pump
Coupler
Battery Lift Strap
Use the battery lift strap to remove and install batteries
from the vehicle. Lift strap allows use of case loops on
battery tops as safe battery lifting points. Obtain battery
lift strap locally.
Figure 7
Battery Hydrometer
Use the battery hydrometer when measuring specific
gravity of battery electrolyte. Obtain hydrometer locally.
Figure 8
