TOS SUA 125 NUMERIC - Page 29

SUA 125 NUMERIC
34200003 TOS a.s. 02/2011
29
size
80
mm
Dead centre:
- taper
1 : 10
ČSN 24 3322
- size
80
mm
- apex angle of centre
60
degrees
Dead centre with nut:
- taper
1 : 10
- size
80
mm
- apex angle of centre
60
degrees
Chuck flange - version:
none
- diameter
mm
Self - centring chuck guard:
Carrier plate, diameter (normal, Camlock)
420
mm
Carriage.
Max. length of working travel:
- longitudinal saddle (longitudinal feed)
1920
mm
- cross slide (cross feed)
650
mm
Tool head / CNC controlled rotary head:
Parat
- size
4
- max. tool size
50
mm
Rapid traverse of carriage:
traverse rate - in longitudinal direction
5
m per min.
- in cross direction
5
m per min.
Chip guard:
yes
Lead screw:
ball circulating
screw
K 63 x 12
- diameter
63
mm
- lead
12
mm
Lead screw guard:
yes
fast guard
Tailstock.
Tailstock sleeve:
- diameter
165
mm
- max. working travel
350
mm
- female taper
1 : 20
- diameter
100
mm
Max. axial force applied to tailstock sleeve:
50 000
N
Tailstock transverse adjustment:
+ 10
mm
Dial indicator for measuring axial force applied to
tailstock sleeve:
yes
Taper adaptor of tailstock sleeve with distance drill
bushing:
yes
Dead centre with distance bush:
yes
