SUA 125 NUMERIC
34200003 TOS a.s. 02/2011
30
- taper
1 : 20
- diameter
100
mm
- apex angle of centre
60
degrees
Power - controlled movement of tailstock:
travel speed
2
m per min.
Electrical equipment:
push button for tailstock movement - to the right
yes
- to the left
yes
Cutting lubricant circuit:
- capacity of cutting lubricant tank
160
l
- nominal rate of flow through the pump
40
l.p.m.
Hydraulic circuit:
- capacity of hydraulic system
0,4
m
3
- nominal rate of flow through hydraulic pump
6
l.p.m.
- recommended hydraulic oil
MOGUL LK 46
Electrical circuits.
Electric motors:
- main motor M1
nominal output
37
kW
nominal voltage
400
V
nominal speed
1 500
r.p.m.
- longitudinal feed of carriage M2
nominal output
5,7
kW
nominal voltage
400
V
nominal speed
2000
r.p.m.
- cross feed of carriage M3
nominal output
4
kW
nominal voltage
400
V
nominal speed
2000
r.p.m.
- power movement of tailstock M4
1LA7080
SIEMENS
nominal output
0,55
kW
nominal voltage
400
V
nominal speed
1 400
r.p.m.
- hydraulic set M5
4AP71-4
SIEMENS
nominal output
0,37
kW
nominal voltage
400
V
nominal speed
1 380
r.p.m.
- circuit of lubricating system
nominal output
0,08
kW
nominal voltage
400
V
nominal speed
2 800
r.p.m.
- circuit of cutting lubricant system
nominal output
0,12
kW
nominal voltage
400
V
nominal speed
2 800
r.p.m.
