CHAPTER 11 OTHER FUNCTIONS
B-EP Series
11-18
NOTE 1: When a command error has been found in the sent command, 16-byte command code of the
erroneous command is displayed on the LCD. (However, [LF] and [NUL] are not displayed.)
[Example 1] [ESC] PC001; 0A00, 0300, 2, 2, A, 00, B [LF] [NUL]
Command error
LCD display
PC001;0A00,0300,
[Example 2] [ESC] T02A G30 [LF] [NUL]
Command error
LCD display
T20A30
[Example 3] [ESC] XR; 0200, 0300, 0450, 1200, 1 [LF] [NUL]
Command error
LCD display
XR;0200,0300,045
NOTE 2: When the command error is displayed, “? (3FH)” is displayed for codes other than 20H to 7FH
and A0H to DFH.
NOTE 3: : Blinking (red)
: ON (red)
{: ON (green or orange)
: Blinking (green)
z: Dimmed
****: Remaining number of labels to be printed 0001 to 9999 (in units of 1 label/tag)
####: Remaining memory capacity of PC save area in the flash memory:
0 to 3,200 (in K bytes)
&&&&: Remaining memory capacity of writable character / basic files / forms / graphics storage area
in the flash memory
0 to 3,200 (in K bytes)
- -: System error No.: 00 to 21
$: Charging error No.: 1 to 5
11.13 LIST OF CHARGING ERROR NO. AND DETAILS
No. Description Cause
1
Battery ID error It is detected that no battery is loaded or that an
inappropriate battery is loaded.
2
Abnormal battery temperature 8.7V or over for B-EP2DL
17.4 V or over for B-EP4DL
3
Abnormal current (during
trickle charging)
1.2A or over for B-EP2DL
2.0A or over for B-EP4DL
4
Trickle charging timeout Transition to normal charging does not take place after trickle
charging for 90 minutes.
5
Abnormal current (during
normal charging)
1.2A or over for B-EP2DL
2.0A or over for B-EP4DL
To Next Page
