Toshiba B-EX4T2 SERIES Manual

1. PRODUCT OVERVIEW
5
1.6 Option
Option Name
Type
Description
Disc cutter module
B-EX204-QM-R
Disc cutter
Each time media is cut, the media feed is
stopped.
Strip module
B-EX904-H-QM-R
This allows use of on-demand (peel-off)
operation or to take-up labels and backing
paper together when using the rewind
guide plate. To purchase the strip module,
please inquire with your local distributor.
203-dpi print head
B-EX704-TPH2-QM-R
This print head enables a conversion of a
300dpi print head of the B-EX4T2-TS
model into 203dpi print head.
300-dpi print head
B-EX704-TPH3-QM-R
This print head enables a conversion of a
203dpi print head of the B-EX4T2-GS
model into 300dpi print head.
600-dpi print head
B-EX704-TPH6-QM-R
Only with B-EX4T2-HS Model
Note: 600-dpi print head is only with B-
EX4T2-HS Model.
RTC & USB host
interface card
B-EX700-RTC-QM-R
This card holds the current time: year,
month, day, hour, minute, second and
provides a USB host interface.
Expansion I/O
interface card
B-EX700-IO-QM-R
Installing this card in the printer allows
connection to an external device with the
exclusive interface.
Parallel interface
card
B-EX700-CEN-QM-R
Installing this card provides a Centronics
interface port.
Serial interface card
B-EX700-RS-QM-R
Installing this card provides an RS-232C
interface port.
Wireless LAN
interface card
B-EX700-WLAN-QM-R
B-EX700-WLAN3-QM-S
Installing this card provides Wireless LAN
communication.
NOTE1
To purchase the optional kits, please contact the nearest authorised TOSHIBA TEC representative or
TOSHIBA TEC Head Quarters.

Toshiba B-EX4T2 SERIES Specifications

General

Print Method	Thermal transfer
Resolution	203 dpi
Print Width	104 mm
Interfaces	USB
Optional Interfaces	Wireless LAN
Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, ITF, Codabar, MSI
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	25 - 85% RH (Non-condensing)
