Toshiba B-EX4T2 SERIES Manual

2.PRINTER SETUP
8
2.1.1 WLAN Module
Installation
Please read below instructions and set up WLAN module to the printer
before use.
Assembly Instructions
<For B-EX700-WLAN-QM-R>
1) Insert the Wireless LAN Card into the slot.
2) Attach the Cover to the printer back with the two M-3x6 screws, as
shown below.
<For B-EX700-WLAN3-QM-S>
Fit the Antenna and LAN Cable as shown below.
M-3x6 Screw
M-3x6 Screw
Antenna
LAN Cable
NOTE:
Be sure to arrange the Antenna so that it is attached vertically.

Toshiba B-EX4T2 SERIES Specifications

General

Print Method	Thermal transfer
Resolution	203 dpi
Print Width	104 mm
Interfaces	USB
Optional Interfaces	Wireless LAN
Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, ITF, Codabar, MSI
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	25 - 85% RH (Non-condensing)
