2.PRINTER SETUP
12
2.3.1 Loading the
Media(Cont.)
8. Place the media between the Media Guides and adjust them to the
media width. Once in the correct position tighten the Locking
Screw.
9. Check that the medias path through the printer is straight. The
media should be to the left side of the print head
In the case of labels rolled with
the print side facing outside.
Media Guide
Locking Screw
Paper Guide
Media Guide
Print Head
Media
In the case of labels rolled with
the print side facing inside.
