Toshiba B-EX4T2 SERIES Manual

2.PRINTER SETUP
17
2.3.2 Loading the Ribbon
(Cont.)
3. Push Ribbon along the Ribbon Shafts to a position where the
ribbon is fully to the Left against the stoppers when fitted.
4. Lower the Print Head Block and set the Ribbon Shaft Holder
Plate aligning its holes with the Ribbon Shafts.
5. Take up any slack in the ribbon. Wind the leading tape onto
the ribbon take-up roll until the ink ribbon can be seen from
the front of the printer.
6. Turn the Head Lever to Label or Tag position to close the Print
Head.
7. Close the Top Cover.
Ribbon Shaft Holder Plate

Toshiba B-EX4T2 SERIES Specifications

General

Print Method	Thermal transfer
Resolution	203 dpi
Print Width	104 mm
Interfaces	USB
Optional Interfaces	Wireless LAN
Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, ITF, Codabar, MSI
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	25 - 85% RH (Non-condensing)
