5 SCAN FUNCTIONS
144 Scanning from e-STUDIO Scan Editor
Editing an image
When you double-click a thumbnail, an edit window opens. You can edit the image using the following icons at
the bottom of the edit window. Click the [Previous Page] icon, the [Next Page] icon, or the Close button to
save the edited image.
1) Previous Page
Shows the previous image in a file window.
2) Next Page
Shows the next image in a file window.
3) Rotate 90 degrees Clockwise
Rotates an image by 90 degrees clockwise.
4) Rotate 90 degrees Anti-Clockwise
Rotate an image 90 degrees anticlockwise
5) Tilt / Skew
Tilts a skewed image. You can select the action to confirm the operation or to execute it without
confirmation on [Editor Options] of the [Preferences] dialog box.
P.149 “Editor Options”
6) Flip
Flips an image upside down.
7) Mirror
Inverts an image horizontally.
