6 VARIOUS FUNCTIONS
176 Network Menu List
Network Menu List
You can set various network functions.
For instructions on how to display the NETWORK menu, see the following page:
 P.179 “User Functions Menu List”
 P.176 “NIC status”
 P.176 “Setting the Ethernet speed”
 P.177 “Setting the TCP/IP protocol”
 P.178 “Setting the HTTP network service”
Once the network has been set up, exit from USER FUNCTIONS menu by pressing [CANCEL] or [USER
FUNCTIONS] button. When “APPLY AND REBOOT?” message appears, select “YES”, and then press
[OK]. The equipment is automatically rebooted and the network settings are applied.
 NIC status
You can confirm the current network communication status.
 Setting the Ethernet speed
You can specify the Ethernet speed.
If the network is not stable, turn the power of the equipment OFF and then back ON.
NETWORK
COMPLETE
NIC STATUS
ETHERNET
NIC STATUS
LINK
CONNECTED:
Item name Description
AUTO
10MBPS HALF DUPLEX
10MBPS FULL DUPLEX
100MBPS HALF DUPLEX
100MBPS FULL DUPLEX
Select the desired combination of communication speed and
transmission method.
ETHERNET
AUTO
10MBPS HALF DUPLEX
10MBPS FULL DUPLEX
