7.TROUBLESHOOTING

Paper Misfeed 203

7 TROUBLESHOOTING

 Paper misfeeds on the Reversing Automatic Document Feeder (RADF)

Open the upper cover.

Open the transport guide and remove the original.

Open the Reversing Automatic Document Feeder.

Turn the dial to remove the misfed original.
