e-STUDIO520/523/600/603/720/723/850/853 © 2005 - 2007 TOSHIBA TEC CORPORATION All rights reserved
FIRMWARE UPDATING
6 - 12
(3) Remove the cover plate.
Fig. 6-8
(4) Connect the download jig with the jig connector (CN107) on the SYS board.
Fig. 6-9
Cover plate
Connector
