e-STUDIO5506AC/6506AC/7506AC (Ver01) © 2016, 2017 TOSHIBA TEC CORPORATION All rights reserved
2-31
2. Copier-specific Adjustments
2.6.2 To Adjust the Copy Image Quality in the Full Color Mode
* You can start with any of the procedures. But it is recommended to perform the procedures in order, as listed
below. You can use one procedure in conjunction with another. But if this changes the image quality more than
required or loses the effectiveness of the adjustment, restore the settings made in the previously used procedure
to the original ones. Then use other procedures.
* Both the service technician and the user can use procedures (1) and (4).
* Only the service technician must use procedures (2) and (3).
(1) Press [AUTO] on the Control Panel to select the automatic density adjustment.
(2) Press [IMAGE] on the Control Panel. Press [BACKGROUND ADJUSTMENT].
Press [LIGHT] to decrease the background density.
After decreasing the background density, copy and check the image quality.
With the background density set to the minimum, if further image quality adjustments are still necessary, the
service technician must use the next procedure.
(3) Select [05 ADJUSTMENT MODE]. Change the values for the following codes below to adjust the density
level of the background.
Adjustment Original mode
[05] code Recommended value
Acceptable
value range
Default
Full color / Auto color
(when judged as color)
Text/Photo
05-7656
Set a value smaller than
128.
0 to 255 128
Text
05-7657
Printed image
05-7658
Full color
05-7659
Map
05-7660
User custom
05-7661
Red seal color
05-7662
* Set the value in increments of approximately 10, while checking the copy image until the optimum value is
obtained.
* The value for the code corresponding to the original mode (Text/Photo, Text, or Printed image) will affect
the copy image quality in the Full color mode and the Auto color mode.
* In the manual density adjustment, images are processed with the highlighting reproducibility given priority.
Therefore it is recommended to select the automatic density adjustment in order to make the background
lighter.
<Note> Making the highlighted area more visible (or increasing the background density)” and
eliminating the background color (or decreasing the background density)” are mutually
contradictory. If the density of the background color is decreased, the highlighted area may
become less visible.
After adjusting the background density, copy and check the copy image quality.
If further image quality adjustments are still necessary, or background elimination is necessary according to
color, use the next procedure.
