4 Replacement Procedures 4.1 General
Removing the Optional Memory
Remove the optional memory (module) according to the following procedures and Figures 4-
4, after checking that the computer is turned off in boot mode.
CAUTION: Remove the optional memory after turning off the computer. If this is
violated, the computer or memory can be damaged.
1. Turn the computer upside down.
2. Release one optional memory cover securing the screw.
3. Remove the memory cover.
CAUTION: Do not touch the connectors on the memory modules or in the computer.
Contaminated connectors can cause memory access problems.
Slot A
Slot B
Memory
Stoper
Memory cover
Nemory cover secure screw
Slot A
Slot B
Memory
Figure 4-4 Removing the optional memory
4. Spread out the two memory lock latches so that the memory module pops up.
5. Pull the memory module up and out at an angle, using care to avoid touching the
connectors.
4-14 Qosmio F40/F45 Maintenance Manual
